Research scientists in the USFS Northern Region (Region 9) – Maine to Minnesota, south to West Virginia and Missouri – continue to be concerned about regeneration patterns of the forest and the future productivity of northern hardwood forests.
The most recent study of which I am aware is that by Stern et al. (2023) [full citation at the end of this blog]. They sought to determine how four species often dominant in the Northeast (or at least in New England) might cope with climate change. Those four species are red maple (Acer rubrum), sugar maple (Acer saccharum), American beech (Fagus grandifolia), and yellow birch (Betula alleghaniensis). The study involved considerable effort: they examined tree ring data from 690 dominant and co-dominant trees on 45 plots at varying elevations across Vermont. The tree ring data allowed them to analyze each species’ response to several stressors over the 70-year period of 1945 to 2014.
In large part their findings agreed with those of studies carried out earlier, or at other locations. As expected, all four species grew robustly during the early decades, then plateaued – indicative of a maturing forest. All species responded positively to summer and winter moisture and negatively to higher summer temperatures. Stern et al. described the importance of moisture availability in non-growing seasons – i.e., winter – as more notable.
snow in Vermont; Putnypix via Flickr
The American Northeast and adjacent areas in Canada have already experienced an unprecedented increase of precipitation over the last several decades. This pattern is expected to continue or even increase under climate change projections. However, Stern et al. say this development is not as promising for tree growth as it first appears. The first caveat is that winter snow will increasingly be replaced by rain. The authors discuss the importance of the insulation of trees’ roots provided by snow cover. They suggest that this insulation might be particularly necessary for sugar maple.
The second caveat is that precipitation is not expected to increase in the summer; it might even decrease. Their data indicate that summer rainfall – during both the current and preceding years – has a significant impact on tree growth rates.
Stern et al. also found that the rapid rise in winter minimum temperatures was associated with slower growth by sugar maple, beech, and yellow birch, as well as red maple at lower elevations. Still, temperature had less influence than moisture metrics.
Stern et al. discuss specific responses of each species to changes in temperatures, moisture availability, and pollutant deposition. Of course, pollutant levels are decreasing in New England due to implementation of provisions of the Clean Air Act of 1990.
They conclude that red maple will probably continue to outcompete the other species.
In their paper, Stern et al. fill in some missing pieces about forests’ adaptation to the changing climate. I am disappointed, however, that these authors did not discuss the role of biotic stressors, i.e., “pests”.
They do report that growth rates of American beech increased in recent years despite the prevalence of beech bark disease. They note that others’ studies have also found an increase in radial growth for mature beech trees in neighboring New Hampshire, where beech bark disease is also rampant.
For more specific information on pests, we can turn to Ducey at al. – also published in 2023. These authors expected American beech to dominate the Bartlett Experimental Forest (in New Hampshire) despite two considerations that we might expect to suppress this growth. First, 70-90% of beech trees were diseased by 1950. Second, managers have made considerable efforts to suppress beech.
Stern et al. say specifically that their study design did not allow analysis of the impact of beech bark disease. I wonder at that decision since American beech is one of four species studied. More understandable, perhaps, is the absence of any mention of beech leaf disease. In 2014, the cutoff date for their growth analysis, beech leaf disease was known only in northeastern Ohio and perhaps a few counties in far western New York and Pennsylvania. Still, by the date of publication of their study, beech leaf disease was recognized as a serious disease established in southern New England.
counties where beech leaf disease has been confirmed
Eastern hemlock (Tsuga canadensis) and northern red oak (Quercus rubra) are described as common co-occurring dominant species in the plots analyzed by Stern et al. Although hemlock woolly adelgid has been killing trees in southern Vermont for years, Stern et al. did not discuss the possible impact of that pest on the forest’s regeneration trajectory. Nor did they assess the possible effects of oak wilt, which admittedly is farther away (in New York (& here) and in Ontario, Canada, west of Lake Erie).
In contrast, Ducey at al. (2023) did discuss link to blog 344 the probable impact of several non-native insects and diseases. In addition to beech bark disease, they addressed hemlock woolly adelgid, emerald ash borer, and beech leaf disease.
Non-native insects and pathogens are of increasing importance in our forests. To them, we can add overbrowsing by deer, proliferation of non-native plants, and spread of non-native earthworms. There is every reason to think the situation will only become more complex. I hope forest researchers will make a creative leap – incorporate the full range of factors affecting the future of US forests.
I understand that such a more integrated, holistic analysis might be beyond any individual scientist’s expertise or time, funding, and constraints of data availability and analysis. I hope, though, that teams of collaborators will compile an overview based on combining their research approaches. Such an overview would include human management actions, climate variables, established and looming pest infestations, etc. I hope, too, that these experts will extrapolate from their individual, site-specific findings to project region-wide effects.
Some studies have taken a more integrative approach. Reed, Bronson, et al. (2022) studied interactions of earthworm biomass and density with deer. Spicer et al. (2023) examined interactions of deer browsing and various vegetation management actions. Hoven et al. (2022) considered interactions of non-native shrubs, tree basal area, and forest moisture regimes.
Stern, R.L., P.G. Schaberg, S.A. Rayback, C.F. Hansen, P.F. Murakami, G.J. Hawley. 2023. Growth trends and environmental drivers of major tree species of the northern hardwood forest of eastern North America. J. For. Res. (2023) 34:37–50 https://doi.org/10.1007/s11676-022-01553-7
Posted by Faith Campbell
We welcome comments that supplement or correct factual information, suggest new approaches, or promote thoughtful consideration. We post comments that disagree with us — but not those we judge to be not civil or inflammatory.
For a detailed discussion of the policies and practices that have allowed these pests to enter and spread – and that do not promote effective restoration strategies – review the Fading Forests report at https://treeimprovement.tennessee.edu/
American bullfrog (Lithobates catesbeianus); photo by Will Brown via Wikimedia; one of invasive animals deliberately introduced to Europe in the past
In February 2024 the European Parliament approved legislation outlawing “ecocide” and providing sanctions for environmental crimes. Member states now have two years to enshrine its provisions in national law.
The new rules update the list of environmental crimes adopted in 2008 and enhance the sanctions. The goal is to ensure more effective enforcement. Listed among the offenses are:
the import and use of mercury and fluorinated greenhouse gases,
the import of invasive species,
the illegal depletion of water resources, and
pollution caused by ships.
This action followed an in-depth analysis of the failures of the previous EU environmental directive, first adopted in 2008 (Directive 2008/99/EC). The review found that:
The Directive had little effect on the ground.
Over the 10 years since its adoption few environmental crime cases were successfully investigated and sentenced.
Sanction levels were too low to dissuade violations.
There had been little systematic cross-border cooperation.
EU Member states were not enforcing the Directive’s provisions. They had provided insufficient resources to the task. They had not developed the needed specialized knowledge and public awareness. They were not sharing information or coordinating either among individual governments’ several agencies or with neighboring countries.
The review found that poor data hampered attempts by both the EU body and national policy-makers to evaluate the Directive’s efficacy.
The new Directive attempts to address these weaknesses. To me, the most important change is that complying with a permit no longer frees a company or its leadership from criminal liability. These individuals now have a “duty of care”. According to Antonius Manders, Dutch MEP from the Group of the European People’s Party (Christian Democrats), if new information shows that actions conducted under the permit are “causing irreversible damage to health and nature – you will have to stop.” This action reverses the previous EU environmental crime directive – and most member state laws. Until now, environmental crime could be punished only if it is unlawful; as long as an enterprise was complying with a permit, its actions would not be considered unlawful. Michael Faure, a professor of comparative and international environmental law at Maastricht University, calls this change revolutionary.
Lorton Prison; via Flickr
Another step was to make corporate leadership personally liable to penalties, including imprisonment. If a company’s actions cause substantial environmental harm, the CEOs and board members can face prison sentences of up to eight years. If the environmental harm results in the death of any person, the penalty can be increased to ten years.
Financial penalties were also raised. Each Member state sets the fines within certain parameters. Fines may be based on either a proportion of annual worldwide turnover (3 to 5%) or set at a fixed fine (up to 40 million euros). Companies might also be obliged to reinstate the damaged environment or compensate for the damage caused.Companies might also lose their licenses or access to public funding, or even be forced to close.
Proponents of making ecocide the fifth international crime at the International Criminal Court argue that the updated directive effectively criminalizes “ecocide”— defined as “unlawful or wanton acts committed with knowledge that there is a substantial likelihood of severe and either widespread or long-term damage to the environment being caused by those acts.”
Individual member states also decide whether the directive will apply to offences committed outside EU borders by EU companies.
Some members of the European Parliament advocate for an even stronger stance: creation of a public prosecutor at the European Union level. They hope that the Council of Europe will incorporate this idea during its ongoing revision of the Convention on the Protection of the Environment through Criminal Law. To me, this seems unlikely since the current text of the Convention, adopted by the Council in 1998, has never been ratified so it has not come into force.
The Council of Europe covers a wider geographic area than the European Union – 46 member states compared to 27. Members of the Council of Europe which are not in the EU include the United Kingdom, Norway, Switzerland, Bosnia-Hercegovina, Serbia, Kosovo, Albania; several mini-states, e.g., Monaco and San Remo; and countries in arguably neighboring regions, e.g., Armenia, Azerbaijan, Georgia, and Turkey.
While I rejoice that invasive species are included in the new Directive, I confess that I am uncertain about the extent to which this inclusion will advance efforts to prevent spread. The species under consideration would apparently have to be identified by some European body as “invasive” and its importation restricted. As we know, many of the most damaging species are not recognized as invasive before their introduction to a naïve environment. On the other side, the requirement that companies recognize new information and halt damaging actions – even when complying with a permit! – provides for needed flexibility.
Posted by Faith Campbell
We welcome comments that supplement or correct factual information, suggest new approaches, or promote thoughtful consideration. We post comments that disagree with us — but not those we judge to be not civil or inflammatory.
For a detailed discussion of the policies and practices that have allowed these pests to enter and spread – and that do not promote effective restoration strategies – review the Fading Forests report at http://treeimprovement.utk.edu/FadingForests.htm
The Eastern deciduous forest is large and important ecologically. The forest is important for biological diversity: it shelters many endangered species, especially plants, molluscs and fish, mammals, and reptiles. In addition, the majority of forest carbon stocks in the U.S. are those of theeastern states.
But the Eastern deciduous forest is also under many anthropogenic stresses – including high numbers of non-native insects and pathogens, Liebhold map high numbers of invasive plants, blog invasive earthworms, blog browsing by overabundant deer, and timber extraction. In the southern portions of the forest, human populations are expanding, resulting in landscape fragmentation (USDA FS 2023b RPA, full reference at end of this blog).
map showing number of non-native pests in each county, as of ~2010
Agency and academic scientists in the USDA Forest Service Eastern Region (Maine to Minnesota; Delaware to West Virginia, then north of the Ohio River to Missouri) are trying to understand how long-term, continuous stressors, like deer browsing and invasive plants and earthworms, – interact with short-term gap-forming events. They call the long-term stressors “press” disturbances to distinguish them from the short-term “pulse” disturbances (Reed, Bronson, et al.; full citation at end of this blog). Understanding the processes by which forests recover from disturbance is increasingly important. Climate change is expected to raise the frequency and intensity of catastrophic natural disturbances (Spicer and Reed, Royo et al.).
The scientists emphasize that the impacts of these stressors – and effective solutions — vary depending on context.
Invasive Earthworms
USDA APHIS is responsible for regulating introduction of new species. For earthworms, APHIS’ principal concern is clearly the possibility that imported worms or soil might transport pathogens. However, the agency’s website does mention worms’ ability to disrupt the soil and possibly cause undesirable impacts on plant growth and diversity. At the 2023 National Plant Board meeting in early August 2023, Gregg Goodman, Senior Agriculturalist in APHIS PPQ NPB website for agenda? discussed issues that he considers when evaluating whether to grant permits for importing earthworms. APHIS allows imports to be used for fish bait. Dr. Goodman explained that APHIS surveyed fishermen to determine where they dump unused bait. He found no damage to plants along streams, etc. where they are dumped. A state plant health official from a northern state and I objected that the ecosystem damage caused by earthworms is well documented and we doubted that dumping of bait is not a pathway for introducing worms into natural areas.
Reed, Bronson et al. found lower earthworm biomass and density in both deer exclosures and canopy gaps. They hypothesize that the new plant growth associated with canopy gaps attracts deer, resulting in increased browse pressure. That browse pressure then affects the plant community, succession and forest structure. The changed plant community affects soil properties that then affect soil-dwelling fauna like earthworms. They believe the higher worm densities in closed-canopy sites might be the result of nutrient-rich tree leaf litter which provides both shelter and food. Another factor might be lack of recent soil disturbances in closed canopy sites.
While they say need more research is needed on the complex, combined effects of earthworms and deer, Reed, Bronson et al. still suggest that reducing deer populations or – where that is not possible – creating gaps might help manage earthworm invasions.
Deer Interactions
The long-term, chronic effect of excessive deer herbivory are well documented. See the many presentations at the recent Northern Hardwood research forum (USDA FS 2023b Proceedings). Most studies show that deer browsing overwhelms other disturbances, such as fire and canopy gaps that typically promote seedling diversity. However, recent results refine our understanding.
Samuel P. Reed and colleagues (Reed, Royo et al.) found that on the Allegheny Plateau of western Pennsylvania high deer densities at the time of stand initiation resulted in long-term reduced tree species diversity, density, and basal area. These responses were still detectable nearly four decades later. Stands are dominated by the unpalatable black cherry (Prunus serotina). The reduced stand density and the cherries’ narrower crowns lead to less above-ground biomass and reductions in above-ground carbon stocks. These scientists recommend that managers reduce deer populations to prevent changes in forest structure with probably long-term and important ramifications for many ecosystem functions.
Prunus serotina; photo by Awinch1001 via Flickr
Hoven et al. concurred with the importance of reducing deer densities, but suggested focussing on wet sites where, in their study, deer browsing had its greatest effects. On drier sites deer browsing had no effect on the diversity of woody plant seedlings.
Spicer et al. seek particularly to maintain a heterogeneous landscape to allow coexistence of both early- and late-successional species. In the Eastern Deciduous Forest biome, herbs, shrubs, and vines comprise 93% of the species richness of vascular plants
These authors found that the impact of deer browsing diverged depending on vegetation management actions. In wind-throw gaps where the plant community was retained, deer caused a 14% decline in shrub cover. In contrast, when scientists removed the extant vegetation at the beginning of recovery, deer exclusion caused a 67% increase in shrub cover. The authors speculate that vegetation removal stimulated abundant blackberry (Rubus species) regrowth. Where they had access (in gaps lacking exclosures), deer heavily browsed young Rubus stalks that sprouted after the competing vegetation was cut down. However, when the pre-established vegetation was not removed, older Rubus thickets might have protected other herbs and shrubs from browsing. Spicer et al. did not observe any major shifts in browse-tolerant species in deer-exclusion plots.
Invasive Shrubs
Hoven et al. found that in drier forest plots, the presence of non-native shrubs reduced native seedling abundance, richness, and diversity. Instead there were more seedlings of introduced species, including Lonicera maackii, L. morrowii, Ligustrum sp., and Rosa multiflora. They are concerned that replacement by invasive honeysuckles might be particularly strong in gaps resulting from death of ash trees caused by emerald ash borer. Woodlands could become dominated introduced shrubs, reducing diversity. Consequently, they recommend removing non-native shrubs in drier forests to promote seedling numbers and diversity.
In contrast, in wetter forests basal area of non-native shrubs did not affect introduced seedling abundance. However, the shrubs’ size did promote greater proportions of Lonicera maackii and Ligustrum seedlings. They suggest this might be the outcome of either abundant seed sources or allelopathic properties of some invasive shrubs e.g., L. maackii. In such sites, seedling diversity is already limited to plants that tolerate waterlogging. A hopeful note is that one native shrub, Lindera benzoin, seems able to prevent establishment of L. maackii.
Lonicera maackii; photo by pverdonk via Flickr
Hoven et al. do worry that death of ash trees might lead to declining transpiration rates, raising water tables, and further reducing seedling species richness and diversity.
Impact of Salvage Logging and Vegetation Removal
Spicer et al. studied how anthropogenic stressors affect succession. These scientists took advantage of tornado-caused gaps to compare interactions with deer browsing, salvage logging, and mechanical removal of the understory.
Contrary to expectations, none of these anthropogenic disturbances delayed community recovery or reduced diversity in comparison to the natural disturbance (tornado blowdown). Instead, adding either salvage logging or mechanical removal of understory vegetation substantially enhanced herbaceous species richness and shrub cover.
However, each major plant growth form responded differently. First, none of the manipulations affected species diversity or abundance of tree seedlings and saplings. Second, salvage logging in the wind-throw gaps increased species richness of herbs by 30%. Shrub abundance was doubled and cover almost tripled, but species richness did not change. Third, removing competing understory vegetation caused an increase of 23% in mean herbaceous cover. I have already discussed the impact of excluding deer.
Spicer et al. greet these increases in species richness with enthusiasm; they recommend managing to create a patchwork of combined natural and anthropogenic disturbances to promote plant diversity. However, I have some questions about which species are being promoted.
This study identified a total of 264 vascular plant species: 40 trees, 190 herbs, 15 shrubs, 17 vines, and 2 of unknown growth form. Only about half of these, 123 species, grew in portions of the mature forest not affected by either the tornado or one of the anthropogenic manipulations.
Gaps contained more plant species – as is to be expected. Natural blowdown areas where no manipulation was carried out had 49 more species than the undisturbed forest community (172 species). Blowdown sites subjected to salvage logging added another 53 species for a total of 225 species, or 102 more than the undisturbed reference forest.
A total of 17 species occurred only once in the authors’ data [= unique species]. Eight of these species grew only in the undisturbed forest. Two grew only in the tornado-impacted plots. Spicer et al. do not elaborate on whether these species are officially rare in that part of Pennsylvania – although it seems they might be. I wish Spicer et al. had addressed whether these possibly rare species might be affected by the forest management they recommend, i.e., intentionally creating a patchwork of various disturbances. An additional seven unique species were found in plots that had been subjected to an anthropogenic disturbance — either salvage logging or removal of remnant vegetation.
nodding trillium (Trillium cernuum); imperiled by restricted range or low populations; photo by Jason Ryndock, Pennsylvania Natural Heritage Program
In tornado-disturbed sites, one native species associated with areas where vegetation was left intact is one of the gorgeous wildflowers of eastern deciduous forests: a Trillium (species not indicated). The one native plant associated with plots from which vegetation was removed was a grass (unspecified).
Spicer et al. report that the proportion of the flora composed of non-native species was very similar between the salvage-logged area (7%) and the undisturbed reference forest (5%). Half of the non-native plant species (3.5% or 9 species) are listed as invasive in Pennsylvania (the article does not list them).
Spicer et al. say these non-native species are relatively uncommon and that they pose a minimal threat. They do concede that the invasive thorny shrub barberry (Berberis thunbergii) was more common in disturbed than intact areas. [I saw plenty of barberry along forest edges in Cook State Forest, which is only 100 miles away from the study site.] I think Spicer and others are too blasé since invasive plant populations can build up quickly when seed sources are present.
Spicer et al. raise two caveats. First, their results regarding the beneficial effects of salvage logging and vegetation manipulation probably will not apply to situations in which vast areas are logged.
More pertinent to us, they warn that their results would also not apply to forest areas in which propagules have been drastically depleted. This can result from previous human land-use or repeated catastrophic disturbances, such as canopy fires. Nor would their results apply to forests that are more threatened by invasive species. They note that a widespread and dense understory of multiple non-native species can create invasional meltdowns, resulting in a lasting depauperate state. This is especially the case when invaders at higher trophic levels, such as earthworms, are part of the mix.
Other Lessons
Reed, Bronson et al. conclude that forest canopies’ responses to disturbance are too variable to be measured by a single method. Evaluating proposals for management will require multiple measures. The overwhelming recommendation of presenters at the recent northern hardwoods research symposium (USDA FS 2023a Proceedings) was to adapt more flexible management strategies to promote forest sustainability and species diversity.
Hovena et al.’s principal finding is that interactions among site wetness, non-native shrubs and the total basal area of trees in the stand had the largest impacts on the species composition of seedlings. In Ohio, site wetness and chronic stressors like deer and introduced shrubs are acting together to shift seedling communities towards fewer native species. Of these three long-term “press” stresses, the interaction between introduced shrubs and soil wetness overshadowed even the impact of deer herbivory on seedling species richness and abundance. Surprisingly, site-specific characteristics – e.g., wetness, canopy tree competition, deer herbivory and introduced shrubs – were more influential than ash mortality in shaping woody seedling communities.
SOURCES
Hoven, B.M., K.S. Knight, V.E. Peters, D.L. Gorchov. 2022. Woody seedling community responses to deer herbivory, introduced shrubs, and ash mortality depend on canopy competition and site wetness. Forest Ecology and Management 523 (2022) 120488
Reed, S.P., D.R. Bronson, J.A. Forrester, L.M. Prudent, A.M. Yang, A.M. Yantes, P.B. Reich, and L.E. Frelich. 2023. Linked disturbance in the temperate forest: Earthworms, deer, and canopy gaps. Ecology. 2023;104:e4040. https://onlinelibrary.wiley.com/r/ecy
Reed, S.P, A.A. Royo, A.T. Fotis, K.S. Knight, C.E. Flower, and P.S. Curtis. 2022. The long-term impacts of deer herbivory in determining temperate forest stand and canopy structural complexity. Journal of Applied Ecology. 2022; 59:812-821
Spicer, M.E., A.A. Royo, J.W. Wenzel, and W.P. Carson. 2023. Understory plant growth forms respond independently to combined natural and anthropogenic disturbances. Forest Ecology and Management 543 (2023) 12077
United States Department of Agriculture. Forest Service. 2023a. Proceedings of the First Biennial Northern Hardwood Conference 2021: Bridging Science and Management for the Future. Northern Research Station General Technical Report NRS-P-211 May 2023
United States Department of Agriculture. Forest Service. 2023b. Future of America’s Forests and Rangelands. Forest Service 2020 Resources Planning Act Assessment. GTR-WO-102. July 2023 https://www.fs.usda.gov/research/treesearch/66413
